True Diversity Wireless Microphone - HW584
-
102
-
21.745.000đ
-
Features
- Dual-channel PLL design.
- UHF200 channel PLL digital lock automatic communication function.
- Adopt IR frequency pairing.
- With display screen (to display frequency, channel, squelch, level, etc.).
- With volume control for each channel.
- AF output (using the “XLR” socket for separate output, and using the microphone interface for mixed output).
- Thông tin sản phẩm
- Bình luận
Description
This product is a professional wireless microphone system. the wireless microphone receiver, which can be combined with several kinds of transmitters to form a wireless microphone system. The combination set includes HW584 (UHF Wireless Microphone System+2 Battery Desktop Wireless Microphones).
Specifications
|
System Index |
Parameters |
|
|
Frequency Range |
632-661.25MHz |
|
|
Number of Channels |
100 |
|
|
Channel Interval |
250KHz |
|
|
Dynamic Range |
82dB |
|
|
Maximum Frequency Deviation |
±45KHz |
|
|
Audio Frequency Response |
120Hz-15KHz (±3dB) |
|
|
SNR |
>70dB |
|
|
Distortion |
≤1% |
|
|
Working Temperature |
-10℃－+40℃ |
|
|
Effective Range |
Max 300m (in open environment) |
|
|
Package Dimensions (L×W×H) |
530×335×220mm |
|
|
HW581 Gross Weight |
5.2kg |
|
|
HW582/HW583 Gross Weight |
4.6kg |
|
|
HW584 Gross Weight |
5.3kg |
|
|
Receiver
|
Wireless Interface |
BNC/50Ω |
|
Sensitivity |
≤-95dBm |
|
|
Display Method |
Display Screen |
|
|
Working Power |
DC12V ,600mA |
|
|
Package Dimensions (L×W×H) |
530×335×100mm |
|
|
Machine Dimensions |
430×176×44mm |
|
|
Gross Weight |
3.9kg |
|
|
Net Weight |
2.3kg |
|
|
Transmitter
|
Antenna Method |
1/4 wave whip antenna for the waistband transmitter, and built-in onboard antenna for the handheld microphone. |
|
Output Power |
High power 14dBm; low power 6dBm |
|
|
Spur Suppression |
-60dB |
|
|
Power Supply |
2 AA 1.5V alkaline batteries |
|
|
Endurance |
More than 10 hours at 14dBm; more than 15 hours at 6dBm. |
|
|
Desktop MIC Rod Length |
420mm |
|
|
Display Method |
Display Screen |
|
|
Handheld MIC Dimensions (Maximum Diameter × Length) |
∅50×265mm (Handheld part diameter ∅34~38mm) |
|
|
Waistband Transmitter Dimensions |
110×64×25mm (excluding antenna length, 80mm more if included) |
|
|
Desktop MIC Dimensions |
151×100×55mm |
|
|
Net Weight of Desktop MIC |
0.45kg |
|
|
Net Weight of Handheld MIC |
0.45kg |
|
|
Net Weight of Waistband Transmitter |
0.1kg |
|
